TigerSaw 1000™

+/- 0,3 mm
Accuracy
600 kg
Max Pushing Capacity
24 meter
Max Length
Wood + Plastics
Material

TigerSaw 1000™

TigerSaw 1000™ is the perfect fully automated optimizing push feed saw station for fast and accurate cutting of wood and plastic materials. It increases yield, accuracy, and productivity at the best value point in the industry, offering uncompromising quality.

Features

  • Adjustable cutting envelope
  • Best in class material optimization with
    Dynamic Optimization™
  • Advanced dust collection
  • Pack/bundle and panel list capability using Dynamic Pack Optimization™ software
    and Flooring Optimization™ software
  • Push up to 80 kg with TigerStop and 600 kg using HeavyDuty
  • TigerLink 6 Cut List Downloading software
  • Download patterns

The Solutions Your Business Needs to Compete

Improved Yields

Dynamic Optimization™ software comes standard and automatically determines the best yield from your cut list. Improved material yield saves money and reduces waste. It allows operators to optimize perfectly, because this push feed saw station is doing the math.

Drop A Grade Of Lumber With Crayon Defect Marking

Operators use a UV Crayon to mark defects in the material. TigerSaw 1000 cuts around those defects and optimizes the clear material while cutting parts. When defecting and optimizing in-house, shops can downgrade to lower cost lumber and retain the same high quality. See your lumber bill shrink with TigerSaw 1000.

Process Pack/Bundles

Cutting bundles dramatically increases throughput (i.e. cutting ten parts at once increases production tenfold). TigerSaw 1000’s adjustable cutting envelope can accommodate pack sizes from 152.4mm x 152.4mm to 25.4mm x 406.4mm envelopes and the HeavyDuty can push loads up to 600 kg.

Tables

Style and Design Meet Durability

TigerSaw 1000 tables are pinch free and designed from cold rolled steel. Choose from a wide array of styles and depths including steel roller tables, plastic roller tables, and 1.5° or 8° tilted tables.

Software

The Software You Need to Succeed

TigerTouch™

Any TigerStop can be enhanced with cutting edge touch screen control with TigerTouch. Using the TigerTouch touch screen controller, you can download an infinite number of cut lists, display three cut lists at a time for easy switching between work orders, and view statistics such as job status, remnants, remaining parts, and yield.

Dynamic Pack Optimization

Dynamic Pack Optimization gives you the best yield by determining the optimal cutting order from your parts list. Improved material yield saves money on raw material and reduces scrap waste. It allows operators to optimize perfectly, because TigerSaw is doing the math.



Value Based Optimizing

This allows the operator to value items in a cut list individually. This will provide complete control over what’s produced first in a cut list even is the most “valuable” pieces are shorter in length.

Flooring Optimization

The Flooring Optimization software upgrade for TigerTouch is perfect for manufacturers of flooring who need to ship finished products in very specific pallet sizes. Flooring Optimization software replaces the need to purchase custom flooring packaging machines.

Dynamic Optimization™

Dynamic Optimization software gives you the best yield by determining the optimal cutting order from your parts list. Improved material yield saves money on raw material and reduces scrap waste. Pair Dynamic Optimization with a laser scanning and defecting pusher foot for even greater throughput.

Report Generation

Reports can be saved in .PDF file format. Custom reports are now possible if the customer’s IT department can tap into our SQL database. TigerStop can provide database schema.

Simulation Tools

Every time a piece of material is run through the TigerSaw 2000, material information is stored, including material length and defects detected. This allows the operator to create an order and run the previously run material against the order off-line. The operator will now know his yields before ever running a stick of material. This greatly assists in job costing.

Cascading Cut Lists

Cascading Cut Lists, runs pattern, push feed, or set point cut lists sequentially, or in a cascading effect, until the entire job is finished. It can be used for processing metal, wood, composites, or plastic.

Accessories

The Right Tool For Any Job

Configure your TigerSaw 1000 with an array of accessories including saw blades, various pusher foots, clamping, and light curtains. You can even attach an AutoLoader Automatic Infeed Station for an increase in productivity

TigerStop UV Scanning Pusher Foot

TigerStop's Scanning Pusher Foot can be used on TigerSaw 1000s and TigerSaw 2000s. Mark...

+ Learn More
TigerStop Mini Gangstop

You can add a 1000mm GangStop pusher foot to your TigerStop.

+ Learn More
HeavyDuty Gangstop

Every HeavyDuty comes standard with a 1000mm gangstop that's robust for pushing up to...

+ Learn More
Spring Buffer 700mm

The Spring Buffer 700mm absorbs impacts from heavy materials and adds additional reach to...

+ Learn More
TigerTouch Tablet Package

TigerStop's Tablet Package includes a touch screen, a protective case, control stand (SMTCS), and...

+ Learn More
Wireless Barcode Scanner Kit

The wireless barcode scanner kit which comes with SET software to communicate to peripheral...

+ Learn More
Wired Barcode Scanner Kit

TigerStop's wired barcode scanner kit which comes with SET software to communicate to peripheral...

+ Learn More
500mm blade solid extrusion
500mm Blade Fine Crosscut

This blade is compatible with the TigerSaw 1000 (second generation saw only) and the...

+ Learn More
500mm blade solid extrusion
500mm Blade Pack Cutting

This blade is compatible with the TigerSaw 1000 (second generation saw system) and the...

+ Learn More
Spring Buffer 1000mm

The Spring Buffer 1000mm absorbs impacts from heavy materials and adds additional reach to...

+ Learn More
Spring Buffer 1300mm

The Spring Buffer 1300mm absorbs impacts from heavy materials and adds additional reach to...

+ Learn More
Thermal Transfer Printer

The Thermal Transfer Printer uses UV resistant ink so labels exposed to sunlight won't...

+ Learn More

TigerSaw 1000 Videos

Video thumbnail
TigerSaw 1000

TigerSaw 1000™ is the perfect automated push feed saw station...

Video thumbnail
TigerTouch

Any TigerStop can be controlled using our patented touch screen...

Video thumbnail
AutoLoader

TigerStop’s AutoLoader is an Automatic Infeed Station that greatly increases...
